280L Horizontal Cylindrical Autoclave HCPS-B280
.....
Detail
280L Horizontal Cylindrical Autoclave HCPS-A280 with Fully Stainless Steel Structure
Features:
Fully stainless steel structure
Microprocessor controlled sterilizing process
Drying function, suitable dressing drying
Over-temperature, over-pressure protection
Door is locked if chamber pressure is above 0.027MPa
Stop run if the door is not closed well
The safety value is opened automatically and steam is exhausted to the water tank when the inner pressure over 0.24MPa
Automatic power off, water cut off and alarm when lacking water
Printer included
Specifications
| Model | HCPS-B150 | HCPS-B200 | HCPS-B280 | HCPS-B400 |
| Chamber volume | 150L | 200L | 280L | 400L |
| Chamber size | φ440×1000mm | φ515×1000mm | φ600×1000mm | Φ700×1100mm |
| Working pressure | 0.22MPa | |||
| Working temperature | 134℃ | |||
| Temperature control range | 105℃ - 134℃ | |||
| Sterilization time | 0-60 min | |||
| Drying time | 0-60 min | |||
| Heat average | ≤±2℃ | |||
| Power | 9KW,380V/50Hz | 9KW,380V/50Hz | 12KW,380V/50Hz | 18KW,380V/50Hz |
| Dimensions | 1350×600×1520 | 1400×670×1650 | 1400×770×1780 | 1430×880×1830 |
| Packing size | 1560×750×1850 | 1560×820×1930 | 1680×920×1950 | 1600×1050×2050 |
| G.W/N.W(Kg) | 312/238 | 350/260 | 465/365 | 530/452 |
