High Speed Refrigerated Floor Standing Centrifuge NovaFuge F113-21R
Detail
High Speed Refrigerated Floor Standing Centrifuge NovaFuge F113-21R
It is widely used in various fields such as agriculture, medicine, food hygiene, biopharmaceuticals, biotechnology, cell biology, and biochemistry; Suitable for the separation and purification of microbial cells, cellular proteins, enzymes, and immunoprecipitates.
Feature:
1. Power coated housing. Universal castors.
2. Reliable drive system. Converter motor maintenance free.
3. Motorized lid locks prevent cover opening during centrifugation.
4. Pneumatic spring supports prevent falling of lid.
5. Manually lid open in case of failure or emergency.
6. Pre-cooling during standstill. CFC free refrigeration system.
7. Microprocessor control of all functions: speed, time, temperature, acceleration/deceleration, RCF, program memory, error display.
8. The self-diagnostic system provides protection for imbalance, over-temperature / speed/voltage, and electronic lock.
*Automatic lid opening at the end of run.
* Short spin.
* Rotor identification.
Technical data
| Model | NovaFuge F113-21R |
| Max. RPM/RCF for angle rotor | 21000rpm / 30053×g |
| Max. RPM/RCF for swing rotor | 6000rpm / 5653×g |
| Max. Capacity for angle rotor | 4×250ml, 48×0.5ml |
| Max. Capacity for swing rotor | 4×750ml, 4×4×5ml |
| Speed increment | 50rpm |
| Speed accuracy | ±20 rpm |
| Temp. range | -20℃~+40℃ |
| Temp accuracy | ±2℃ |
| Timer range | 1min~99min |
| Acc / Dec rates | 12/12 |
| Power supply | AC220V 50/60Hz |
| Power requirement | 1.75KW |
| Noise | <58db |
| Display | Digital display |
| Motor | Converter Motor, direct drive |
| Net weight (without rotor) | 156kg |
| Machine Dimension（L×W×H） | 630×740×1040mm |
