Low Speed Floor Standing Centrifuge NovaFuge F242-5K
It is widely used in clinical medicine, clinical laboratory, biological engineering, Genetic engineering, immunology. It is suitable for the separation and purification of radioimmunoassay, water analysis, biochemistry, pharmaceutical and blood products.
Feature:
1. Power coated housing. Universal castors.
2. Reliable drive system. Converter motor maintenance free.
3. Motorized lid locks prevent cover opening during centrifugation.
4. Pneumatic spring supports prevent falling of lid.
5. Manually lid open in case of failure or emergency.
6. Pre-cooling during standstill. CFC-free refrigeration system (only for refrigerated models).
7. Recall of last settings. Parameters can be changed during operation.
8. Microprocessor control of all functions: speed, time, temperature, acceleration/deceleration, RCF, program memory, error display.
9. The self-diagnostic system provides protection for imbalance, over-temperature / speed/voltage, and electronic lock.
Automatic lid opening at the end of run.
Short spin.
Rotor identification.
Program memory( Only for NovaFuge F241-5R and NovaFuge F242-5K)
Technical data
Model | NovaFuge F241-5R | NovaFuge F242-5K | NovaFuge F105-5R | NovaFuge F104-5K |
Max. RPM/RCF for angle rotor | 5000rpm / 3525×g | |||
Max. RPM/RCF for swing rotor | 5000rpm / 4633×g | |||
Max. Capacity for angle rotor | 12×15ml | |||
Max. Capacity for swing rotor | 4×1000ml, 148×5ml | |||
Speed increment | 50rpm | |||
Speed accuracy | ±20 rpm | |||
Temp. range | -20℃~+40℃ | - | -20℃~+40℃ | - |
Temp accuracy | ±2℃ | - | ±2℃ | - |
Timer range | 0~99min50s / 23h59min | 1min~99min | ||
Acc / Dec rates | 12/12 | - | ||
Program memory | *30 | - | ||
Power supply | AC220V 50/60Hz | |||
Power requirement | 1.75KW | 1KW | 1.75KW | 1KW |
Noise | <58db | |||
Display | LCD screen | Digital display | ||
Machine Body | Metal frame | |||
Motor | Converter Motor, direct drive | |||
Net weight (without rotor) | 165kg | 140kg | 150kg | 133kg |
Machine Dimension(L×W×H) | 630×740×900mm | 630×740×1040mm |
