Product Detail

Low Speed non-refrigerated Benchtop Centrifuge NovaFuge B138-4K(LED)
.....
Detail

Low Speed non-refrigerated Benchtop Centrifuge NovaFuge B138-4K(LED)

It is suitable for the liquid’s separation in biochemistry, laboratory, pharmaceuticals, bioproducts, and other fields.

Feature:

1.     Power coated housing. Stainless steel chamber with guarding ring.

2.     Reliable drive system.

3.     Electronic safety lock prevent cover opening during centrifugation.

4.     Manually lid open in case of failure or emergency.

5.     Pneumatic spring supports prevent falling of lid.

6.     Recall of last settings. Parameters can be changed during operation.

7.     Microprocessor control of all functions: speed, time, temperature, *acceleration/deceleration, RCF, error display.

8.     The self-diagnostic system provides protection for imbalance, over-temperature / speed/voltage, and electronic lock.

9.     Produced according to national and international safety standards (ISO9001, ISO13485, ISO14001, EN IEC 61010, EN IEC 61326).

10.  * Optional: Automatic lid opening at the end of run.

* Short spin.


Technical data

ModelB138-4K(LCD)B136-4KB138-4K(LED)
Max. RPM/RCF for angle rotor4000rpm / 3312×g
Max. RPM/RCF for swing rotor4000rpm / 2673×g-
Max. Capacity for angle rotor6×50ml, 18×10ml6×50ml, 24×10ml6×50ml, 18×10ml
Max. Capacity for swing rotor4×50ml, 12×10ml-
Speed Increment10rpm10rpm10rpm
Speed Accuracy±20rpm
Timer Range0min~99min59s1min~99min
Acceleration / Deceleration rates10/10--
Power SupplyAC220V / 50~60Hz
Power Requirement200W60W
MotorVariable frequency motorBrushless motor
Noise<55db
ScreenLCDLED
Machine BodyPlastic and metal frameMetal frame
Net Weight (without rotor)22kg21kg19kg
Machine Dimension(L×W×H)340×480×290mm350×440×260mm
