Low Speed non-refrigerated Benchtop Centrifuge NovaFuge B138-4K(LED)
It is suitable for the liquid’s separation in biochemistry, laboratory, pharmaceuticals, bioproducts, and other fields.
Feature:
1. Power coated housing. Stainless steel chamber with guarding ring.
2. Reliable drive system.
3. Electronic safety lock prevent cover opening during centrifugation.
4. Manually lid open in case of failure or emergency.
5. Pneumatic spring supports prevent falling of lid.
6. Recall of last settings. Parameters can be changed during operation.
7. Microprocessor control of all functions: speed, time, temperature, *acceleration/deceleration, RCF, error display.
8. The self-diagnostic system provides protection for imbalance, over-temperature / speed/voltage, and electronic lock.
9. Produced according to national and international safety standards (ISO9001, ISO13485, ISO14001, EN IEC 61010, EN IEC 61326).
10. * Optional: Automatic lid opening at the end of run.
* Short spin.
Technical data
Model | B138-4K(LCD) | B136-4K | B138-4K(LED) |
Max. RPM/RCF for angle rotor | 4000rpm / 3312×g | ||
Max. RPM/RCF for swing rotor | 4000rpm / 2673×g | - | |
Max. Capacity for angle rotor | 6×50ml, 18×10ml | 6×50ml, 24×10ml | 6×50ml, 18×10ml |
Max. Capacity for swing rotor | 4×50ml, 12×10ml | - | |
Speed Increment | 10rpm | 10rpm | 10rpm |
Speed Accuracy | ±20rpm | ||
Timer Range | 0min~99min59s | 1min~99min | |
Acceleration / Deceleration rates | 10/10 | - | - |
Power Supply | AC220V / 50~60Hz | ||
Power Requirement | 200W | 60W | |
Motor | Variable frequency motor | Brushless motor | |
Noise | <55db | ||
Screen | LCD | LED | |
Machine Body | Plastic and metal frame | Metal frame | |
Net Weight (without rotor) | 22kg | 21kg | 19kg |
Machine Dimension(L×W×H) | 340×480×290mm | 350×440×260mm |
