It is suitable for the liquid’s separation in biochemistry, laboratory, pharmaceuticals, bioproducts, and other fields.
Feature:
1. Power coated housing. Stainless steel chamber with guarding ring.
2. Reliable drive system. Variable frequency motor maintenance free.
3. Electronic safety lock prevent cover opening during centrifugation.
4. Manually lid open in case of failure or emergency.
5. Pneumatic spring supports prevent falling of lid.
6. Recall of last settings. Parameters can be changed during operation.
7. Microprocessor control of all functions: speed, time, *acceleration/deceleration, RCF, *program memory, error display.
8. The self-diagnostic system provides protection for imbalance, over-temperature / speed/voltage, and electronic lock.
9. Optional:
*Automatic lid opening at the end of run.
*Short spin function (NovaFuge B127-6K(LED) only).
Technical data
Model | NovaFuge B127-6K(LCD) | NovaFuge B127-6K(LED) |
Max. RPM/RCF for angle rotor | 6000rpm / 5076×g | |
Max. RPM/RCF for swing rotor | 4000rpm / 3617×g | |
Max. Capacity for angle rotor | 12×15ml, 24×10ml | |
Max. Capacity for swing rotor | 4×500ml, 96×5ml | |
Speed increment | 50rpm | |
Speed accuracy | ±20rpm | |
Timer range | 0min~99min59s | 1min~99min |
Acc / Dec rates | 10/10 | - |
Program memory | 35 | - |
Short spin function | √ | - |
Power supply | AC220V / 50~60Hz | |
Power requirement | 750W | |
Noise | <55db | |
Display | LCD Screen | Digital display |
Machine body | Metal frame | |
Net weight (without rotor) | 55kg | 54kg |
Machine dimension(L×W×H) | 490×610×400mm |
